VISI Reverse is a high level software solution at an affordable price for 3D reverse engineering, 3D geometry reconstruction, topography, medical applications and many other disciplines.

VISI Reverse is a high level software solution at an affordable price for 3D reverse engineering, 3D geometry reconstruction, topography, medical applications and many other disciplines. The 3D point cloud used to construct the 3D model can come from any measurement system or technology including 3D scanners, digitizer, CMM, laser point, laser trackers, laser plane (laser triangulation), time-of-flight laser (lasergrammetry), photogrammetry or stereophotogrammetry.

Using VISI Reverse it is possible to enter millions of points without limitation and create a meshed model in a very short time frame. VISI Reverse implements new technologies such as mesh refinement and automatic edge detection to provide high quality 3D geometry reconstruction and accurate meshed models even with poor quality point cloud input.

VISI Reverse is the latest solution in this market with a focus to provide the fastest and most accurate tool for points, meshes and simultaneous geometry management. It combines the powerful versatility of point cloud management with the speed of automatic curve and surface creation, providing a complete solution for free-form designers, product engineers, modellers, prototype specialists and inspection analysts. The models generated from VISI Reverse can be used directly for rapid prototyping, tool path generation, animation, simulation, finite element analysis, control and inspection, sectioning and many other downstream processes.

Features at a glance:

• Dynamic mesh generation from point cloud

• Point cloud merge and registration

• Geometry rebuild from limited point data

• Accurate curvature meshing

• Non-manifold geometry correction

• Mesh offset

• Mesh cut with curve

• Automatic edge recognition

• Management of edges, curves and surfaces

• Automatic surface generation

• Evaluation of point cloud approximation

Powerful point clouds processing. VISI Reverse imports both point-cloud and polygon-mesh data acquired from various 3D scanners and measurement device types. A 3D point cloud obtained from any measurement system can be easily and quickly processed and transformed into a watertight meshed model valid for any purpose. There is also a special tool that allows the registering and merging of different clouds or meshes into a single model. Point cloud processing is very powerful and it is possible to apply tools for smart point number reduction; such tools include noise and redundancy cleaning, filtering, smoothing and many others. There are also functions for point number increase including refinement and point addition which allows geometry to be rebuilt even from a lesser number of points.

Fast and accurate mesh management. Starting from a point cloud, VISI Reverse automatically creates a dynamic triangulated mesh. Mesh generation is equally fast and accurate and includes curvature meshing to preserve sharp edges and radii. There are many tools for further mesh processing which include : repairing corrupted STL files; elimination of spike and abnormal and irregular triangles; non-manifold geometry correction; smoothing, normal fixing and decimation; fitting selected mesh parts to planes, cylinders, spheres or cones; partial or complete hole filling that is flat or curvature based; bridge between meshes; defeature, and boundary fitting to curves to name only a few. VISI Reverse also considers mechanical digitisation process and provides an offset mesh for probe radius compensation. Once generated and refined it is possible to export the resulting triangle mesh into one of the popular formats for 3D mesh models, such as STL, VRML, OBJ and others.
