Products
1.Performs dual functions - oil extracting and draining.
2.The oil flow is visual through a clear cup.
3.Filter net screens out impurities to protect the motor and the pump. Machine service life is prolonged.
4.Oil is driven by the motor pump; therefore, the oil can be extracted immediately. It differs from the vacuum type in that the extracting procedure is to vacuum the tank first, and then to extract the oil.
5.It can be used for extracting engine oil, transmission oil, gear oil, and lubricant.
6.A 520mm, extra large draining bowl prevents waste oil from spilling. It saves the troubles of using conventional plastic draining bowls, which may be aged, fragile or deformed.
7.Applying the patented automatic retraction design, it is unnecessary to raise and hold down the funnel manually for draining oil.
8.Use stored pressure to drain the oil. The operation is easy.
9.An optional accessory (N-shape pipe) can be installed to allow the machine to turn 360° for the convenience of extracting and draining oil. It is suitable for runway type lifters.
10.Optional accessories are available to satisfy customers' special needs. Its usage can be diversified.
11.One machine with two functions, saving work space and equipment expenditures.
12.Patent No.88653 & No.89440.
13.Driven by the pneumatic motor pump.
Model
|
Capactiy
|
Used Pressure
|
Power
|
Machine Size
|
Hose Accessories
|
Discharge Style
|
Packaging
|
N.W
|
G.W
|
HD-806
|
80 L
|
5~7 kg/cm2
|
AP-35
|
520 × 520 × 1080~1570
|
A.B.C.D.E
|
Air Pressure
|
6.3' / 1.6'
|
30/3 kgs
|
32/4 kgs
|
|
|||
|
|||
|
