訂貨編號 Order No. | 規格 Model | 範 圍 D Boring Range ψDMin-ψDMax | 組合系統-主軸柄規格 Taper Shank | L1 | 淨重 N.W | |
16910410 | NT40-HNBJ16 | 6-51 | H63 | DIN2080 ISO40-H63-55 | 55 | 9.3 |
16910510 | NT50-HNBJ16 | 6-51 | H63 | DIN2080 ISO50-H63-65 | 65 | 11.2 |
16911410 | BT40-HNBJ16 | 6-51 | H63 | MAS403 BT40-H63-55 | 55 | 9.1 |
16911510 | BT50-HNBJ16 | 6-51 | H63 | MAS403 BT50-H63-65 | 65 | 11.7 |
16911512 | BT50-HNBJ16 | 6-51 | H63 | MAS403 BT50-H63-85 | 85 | 12.2 |
16912410 | SK40-HNBJ16 | 6-51 | H63 | DIN69871A ISO40-H63-60 | 60 | 9.1 |
16912510 | SK50-HNBJ16 | 6-51 | H63 | DIN69871A ISO50-H63-65 | 65 | 10.9 |
16914610 | HSK63-HNBJ16 | 6-51 | H63 | DIN69893A HSK63-H63-67 | 67 | 9.0 |
訂貨編號 Order No. | 搪孔刀桿 Cutting Bar | 範 圍 D Boring range ψDMin-ψDMax | 深度 DM | 刀片 Insert | 螺絲 Bolt | 板手 Wrench | 淨重 N.W. |
16010624 | BJ1606-24 | 6-9 | 24 | WBGT0601..L | SB-1STR-M2 | T6 | 0.08 |
16010832 | BJ1608-32 | 8-11 | 32 | TBGT0601..L | 0.08 | ||
16011040 | BJ1610-40 | 10-13 | 40 | 0.08 | |||
16011253 | BJ1612-53 | 12-15 | 53 | TPGH0902..L | SB-2TR-M2.5 | T8 | 0.10 |
16011460 | BJ1614-60 | 14-17 | 60 | 0.10 | |||
16011668 | BJ1616-68 | 16-21 | 68 | 0.12 | |||
16012083 | BJ1620-83 | 20-26 | 83 | TPGH1103..L | SB-3TR-M3 | 0.20 | |
16012590 | BJ1625-90 | 25-31 | 90 | 0.30 | |||
16013090 | BJ1630-90 | 30-36 | 90 | 0.32 | |||
16013590 | BJ1635-90 | 35-41 | 90 | 0.32 | |||
16014090 | BJ1640-90 | 40-46 | 90 | 0.38 | |||
16014590 | BJ1645-90 | 45-51 | 90 | 0.38 |
