Specification
Instruction / Model. | KCD-1520 |
Capacity of CBN wheel | 130 ~ 200 mm |
Thickness of CBN wheel | 1.2 mm ~ 12 mm |
Wheel inner diameter | 32 mm |
Wheel motor | 0.375 kw / 4p |
Wheel rotating speed | 600 ~ 1500 rpm |
Total electric power | 0.5 kw |
Gross weight | 192 kgs |
Dimension (W x H x D) | 690 x 1420 x 640 mm |
* The specifications subject to change without prior notice. |
