● Stable lubrication of each lubrication point.
● Start-up lubrication, power-off memory function.
●With one-way valve setting, oil doesn’t flow back, fully guarantee lubrication.
● With overheat protection, the motor is durable.
Warranty Period:2 Years
Min.Order Quantity:1 Piece/Pieces
Supply Ability:10000 Piece/Pieces per Month
Performance and characteristics
1,Provided with liquid level switch and pressure switch (optional). When oil volume or pressure is insufficient, the beeper makes sound, send alarm and offers abnormal signal output
2,The panel indicator displayed lubricating and intermittent status.
3,The system is provided with FEED keys, and compulsory lubrication is applied.
4,The longest lubricating time less than or equal to 2 min, and intermittent time is 5 times of the lubricating time.
5,The motor is provided with self-protection function to avoid high motor temperature and overload
6,Decompression device is provided with volumetric system, used with proportional joint distributor.
7,Overflow is provided with to protect oil injector and pipeline from being damaged by high pressure.
8,Internal fuse is provided to prevent IC board and motor damaged by short circuit.
