Specification
Remark:
Standard accessories = one roll of filter paper (inside the device)
The downspout and support bracket are special accessories
Special water tank can be customized
Description:
- L : Coolant tank capacity
- A : Overall length
- B : Overall width
- C : Overall height
- D : Tank length
- E : Tank width
- F : Coolant inlet height(Center height)
- G : Coolant inlet port
- H : Inlet coolant tank height
Specifications
| Model | Processing capacity L/min |
L | A | B | C | D | E | F | G | H | Paper width | Conveyor motor | Pump motor & coolant outlet port |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MDSP-20 | 20 | 100 | 1200 | 710 | 680 | 1000 | 620 | 510 | 1-1/2"PT | - | 500 | 25W | 1/8HP-1/2"PT |
| MDSP-40 | 40 | 120 | 1300 | 710 | 680 | 1100 | 620 | 510 | 2"PT | 650 | 500 | 25W | 1/8HP-1/2"PT |
| MDSP-60 | 60 | 150 | 1450 | 710 | 680 | 1250 | 620 | 510 | 2"PT | 655 | 500 | 25W | 1/8HP-1/2"PT |
| MDSP-80 | 80 | 170 | 1600 | 710 | 680 | 1400 | 620 | 525 | 2"PT | - | 500 | 25W | 1/4HP-1/2"PT |
| MDSP-120 | 120 | 220 | 1710 | 890 | 690 | 1460 | 800 | 505 | 3"PT | - | 700 | 40W | 1/4HP-1/2"PT |
| MDSP-160 | 160 | 260 | 1930 | 910 | 690 | 1680 | 820 | 530 | 3"PT | - | 700 | 40W | 1/2HP-3/4"PT |
| MDSP-240 | 240 | 360 | 1980 | 1210 | 730 | 1730 | 1120 | 503 | 3"PT | - | 1000 | 60W | 1HP-1"PT |
