Grinding Coolant Filter System
Centrifugal Separator CL-100
CL-100
Feature
Suitable for oil or water base coolant fluids.
There is no consumption of the filtering material.
Must manually clean inside of the fan-blade housing.
Suitable for ceramic, glass and other non-metal material filtration.
Operation Principle
Coolant pump motor rotates at high speed to drive fan-blade within the housing to create exceptional centrifugal force.
When the coolant flows into the fan-blade housing, heavy chips or residues will attach themselves to the inner wall of the housing. Mass lighter than coolant’s residue will drift around fan-blade housing’s inner wall toward the top side, collected together, and then finally flow out from the output hose.
Specification
Specifications
Model | Procrssing capacity L/min |
A | B | C | D | E | F | G | Pump motor |
---|---|---|---|---|---|---|---|---|---|
CL-100 | 100 | 900 | 520 | 1625 | 720 | 985 | 1-1/4"PT | 3"PT | 3HP/2.2KW |
