1. Adopt with flat face mill cutting. In order to save the cutter costs. You can swivel base angle to make the cutter flute to be recycle used.
2. Available for 2 functions adjusting. The original for L type chamfering ( Fig 1) ; the new for V type chamfering ( Fig 2).
3. For V type chamfering : save energy. Also the surface of workpeice will be more smoothly after chamfered.
4. PATENT model.
MODEL | JT-100C |
Capacity, (Old - L mode) | 0~3 m/m |
Capacity, (New - V mode) | 0~5 m/m ( 2 times processing) |
Table size | 100 X 70 m/m |
Motor | 100V ~ 240V 50/60Hz 1PH |
Speed | 11000 r.p.m. |
Variable speed(Optioan) | 2800 ~ 11000 r.p.m. |
Non Load Motor | 670W 6.0A |
Cutter Size | SPMW 0903 ADTR |
NW/GW | 2.4 / 2.8 kgs |
Packing | 38cm X 13cm X 14cm |
