Specification
- Standard Rated Voltage (VDC):1.5
- Max. Operating Voltage (VDC):9.0
- Max. Current Consumption (mA):0.4@Vs=1.5V D.C. RL=2.0K ohm
- Sensitivity (dB):-37+/-3
- Impedance (Ω):2.2K
- Frequency Range(Hz):100~20,000
- Sensitivity Reduction (dB):-3dB@f=1KHz, 1Pa, Vs=1.5V D.C. to 1.0V D.C.
- Storage Temperature (℃):-20~+70
- S/N Ratio (dBA):72
- Dimension (mm):Ф9.7x4.5
