EUROPEAN STYLE GEAR BOX
MODEL: AS type
Output Shaft: Ø 16, Ø 19, Ø 25
Ratio: 1:5.02~192.1
Horse Power: 1/4~2HP
Input Flange: IEC 63B5, 71B5, 80B5, 90B5

The TPG AS Series Helical In-Line Reducer introduces a modern European-style design, optimized to handle higher overhung and thrust loads on the low-speed shaft. It offers improved torque distribution for greater durability, low noise, and a more compact structure compared to traditional designs.

Specifications: Service factor >1, gear ratios ranging from 5.53 to 187.5, available sizes: 16, 20, and 25. Flexible mounting options include flange and foot configurations, with both single and double shaft outputs. Compatible with a wide range of motors for cost-efficient performance.

AS16/20: Constructed with die-cast aluminum (ADC12) housing, offering a lightweight, reliable structure with a modern aesthetic. Internal components are interchangeable between sizes, reducing spare part costs and inventory requirements.

AS25: Features a cast steel (FC25) housing designed for higher torque loads. Reinforced bearings and precision heat-treated gears ensure exceptional durability and stability.

Applications: Ideal for circular weaving machines, agitators, food processing machines, milling machines, textile equipment, and more.
