Products

Slide
Heavy Duty Horizontal Seat
HUS-200

Specification

Model Suitable Primary Spindle Max. loading Micro-adjusting Type Distance Height range Weight
HUS-200 Drilling Head -HD6
Tapping Head -HN7
Spindle Head-S40
150kg Hand wheel with scale 60 Max:320
Min:260
64kg

A:Touch in structure, is able to perform heavy cutting

B:Using F25C cast iron with special heat treatment, suitable for precision fabrication.

C:Manual hand wheel for micro-adjusting,saving engrgy in automation。

D:Keyway dimension 20x7

E:Welcome order spical Size
