Standard Uncoiler & Straightener
TGL Series

Features
The 2 in 1 Standard Uncoiler & Straightener :
Save space.
Easy loading coil material and operation .
The upper work rollers adopt 4 worm gear micro adjusters.
High Quality and Precision :
TGL rollers made by mild steel, quenched, hard-chrome plated and ground to hardness HRC 60°.
CCompatible with other feeders.
The TGL series can also be used in the long length cutting lines.
TGL can be special ordered and designed to achieve the non-shift speed with optional accessories such as coil hold down arm, hydraulic mandrel expansion and more for increased safety and efficiency.



Specification

Specification

Item

TGL-200

TGL-300

TGL-400

TGL-500

TGL-600

Width of Material (mm)

200

300

400

500

600

Thickness of Material (mm)

0.5 ~ 3.2

Max. Coil Weight (kg)

600

1000

1500

2000

Max. Coil I.D. (mm)

460 - 520

Max. Coil O.D. (mm)

1000

1200

Max. Speed (m/min)

15

Feed Roller

2

Pinch Roller

2

Work Roll

upper*3 / lower*4
Lower Roller Driven Function

Straightening Performance

N / A

Uncoiler Expansion

Manual

Uncoiler Motor (HP)

N / A

Straightener Motor ( HP)

1

2

3

Loop Control

Touch sensor

Feed direction (mm)
Feed height

Customer request
