Air Conveyor
TM Series

Features
These low profile, belt less conveyors are pneumatically powered. The rhythmic vibrations transport parts and scrap and save you money. Trays can be fabricated to suit any size opening and to separate different sized scrap materials.

Specification

Specification

Item

TM-12

TM-48

TM-100

Load Capacity (kg)

12

48

100

Air Consumption (L/min)

14

46

130

Feed Rate (SPM)

120

100

80

Sound Level (DB-A)

68

68

69

Stroke Length (mm)

24

26

27

Max. Tray Weight (kg)

2.9

5.8

20

Air Pressure Range (kg/cm )

3.5 - 5.5

3.5 - 5.5

3.5 - 5.5

Max Incline of Tray

Shipping Weight (kg)

2.5

6.5

18.2
