NC Roll Feeder
TNC Series

Features
Unique Japanese technology design
Reliability & rigid structure
High precision & durability
High productivity

Specification

Specification

Item

TNC-200

TNC-300

TNC-400

TNC-500

TNC-600

Width of Material (mm)

200

300

400

500

600

Thickness of Material (mm)

Max 2.5

Max 3.2

Feeding Capacity

200*2.3

300*2.0

400*1.6

500*1.2

600*1.0

80*3.2

80*3.2

50*3.2

200*3.2

150*3.2

Max. Feed Length (mm)

9999.99

Feed Pitch Accuracy (mm)

±0.15 mm

Roll Pressure

Spring Type

Releasing System

Pneumatic Type

Pass Line Adjust (mm)

±50 mm

Power Supply

AC 220V/3 Phase

Standard Accessories

1. Remote Operating Switch
2. Entrance Catenaries Table
3. Hard Chrome Plated Roll
