Standard Accessories:
Full splash guard
Cutting coolant unit
Heat exchanger in control box
Auto power off
Auto lubrication system
Air blast through spindle
Work lamp
Tool box
Armless (Carousel) type ATC (16 tools)
Rigid tapping
Operation manual and electric drawing equipment
RS-232 Interface
Spindle oil cooler unit
Optional Accessories:
4th axis interface
CNC rotary table
Spindle 10,000 RPM or 12,000 RPM
Arm type ATC (24 tools)
Screw type chip conveyor
Link chain type conveyor
ZF 2 speed gear box
Rear coolant flushing device
Coolant through tool holder
CNC control: The machine is equipped with a Fanuc 0i-MC CNC control as standard equipment. Upon request, Anilam, Fagor, Mistsubishi controls are available.
| MODEL | JMV-1100 | JMV-1300 | ||
| TRAVEL | ||||
| X-axis travel | 1,100 mm | 1,300 mm | ||
| Y-axis travel | 600 mm | 650 mm | ||
| Z-axis travel | 600 mm | 600 mm | ||
|
Distance from table |
120-720 mm | 120-720 mm | ||
| TABLE | ||||
| Table area | 1,250 x 650 mm | 1,450 x 650 mm | ||
| Max. load of table | 880 Kg | 1,000 Kg | ||
|
T-slot |
5 x 18 mm x 125 mm | 5 x 18 mm x 125 mm | ||
| SPINDLE | ||||
| Spindle taper | BT 40 | BT 40 | BT-50 opt. | |
| Max. spindle speed | 8,000 rpm | 8,000 rpm | 6,000 rpm (opt.) |
|
| Spindle cooling | Oil chiller | Oil chiller | ||
| Spindle motor | 7.5 / 11 KW (10HP) |
11 / 15 KW (15HP) |
15 / 18.5KW (20HP) |
|
| FEED RATE | ||||
| Rapid traverse (X,Y) |
18 m/min | 18 m/min | ||
| Rapid traverse (Z) |
15 m/min | 15 m/min | ||
| Cutting feed rate | 1-10,000 mm/min | 1-10,000 mm/min | ||
|
3 axes motor |
3.0 KW | 4.0 KW | ||
