Specification
Max. stroke of ram: 910
Stroke feeds: 8
Range of stroke per min.: 6-80
Max. planing width(standard): 910
Max. distance table toram: 550
Vertical travel of tool head: 210
Table feeds: 11
Range of table feeds: 0.15~2.0
Vertical travel of table: 330
Dimensions of table(Lxw): 750x750
Motor(HP): 3.75HP
Weight(kgs): 2600kgs
|
Measurment: 2270x1540x1850
Standard Accessories Vise 20" (500x500x90mm):1 set
