Specification
Product Description
| Cross Slideways | Cross Movement | Vertical Downfeed | Auto Down Feed | Rotary Table |
|---|---|---|---|---|
| Double Vee Ways | Servo Control | Rapid Up/Down | AD1 Standard | Bearings/Hydrostatic |
- The surfaces of longitudinal table ways are all hand scraped to getting perfect contact pattern and to ensure very high accuracy.
- ongitudinal table ways are designed to have slide surfaces longer than that of the working surface and equal to the table length to keep the table free from torsion and deflection(except PSGS series).
Product Feature
| SPECIFICATION / MODELS | PSRS | |||
|---|---|---|---|---|
| 200S | 300S | 400S | ||
| General Capacity | Max. grinding radius | 120mm | 160mm | 220mm |
| Spindle center height from table | 300mm | 350mm | 400mm | |
| Table diameter | 200mm | 300mm | 400mm | |
| Rotary Table | Max. speed | 10-100 r.p.m. | ||
| Table motor | 0.4kW | 0.75kW | 1kW | |
| Cross Movement | Continuous cross feed | 1100mm/min | ||
| Hand feed per revolution | - | |||
| Hand feed per division | - | |||
| Vertical Downfeed | Rapid traverse approx. (option) | 220mm/min | ||
| Handwheel per revolution | 0.1mm x1/x5/x10 | |||
| Handwheel per divison | 0.001mm x1/x5/x10 | |||
| Grinding Wheel | Dimension (O.D x W x I.D) | 180x13x21.75 | 355x38x127 | |
| Spindle speed(50/60Hz) | 1500/1800 r.p.m. | |||
| Motor | Spindle motor | 3.7kW/5HP | ||
| Weight | Net weight | 850KG | 1400KG | 1650KG |
| Gross weight | 930KG | 1600KG | 1800KG | |
| Machine Size | Dimension(L x W x H) | 1.4x1.5x2.1 | 1.6x1.6x2.1 | 1.8x1.6x2.1 |
Notes:
- Since we subscribe to a process of continuous improvement for our products specifications are subject to change without notice.
- Machine appearance will change depending upon different optional equipment selected.
- Equipment marked with () is available at additional extra charge. Other special applications may be provided upon specific requests from customers. Please contact us for more details.
- Machines are shown with optional equipments.
