Specification
| Dim\Model | TF2B-4 | TF2B-5 | TF2B-6 | TF2B-8 | TF2B-10 | TF2B-12 | TF2B-15 |
|---|---|---|---|---|---|---|---|
| Jaw Stroke (Dia)(mm) | 5.4 | 5.4 | 5.5 | 7.4 | 8.8 | 10.6 | 10.6 |
| Plunger Stroke (mm) | 10 | 10 | 12 | 16 | 19 | 23 | 23 |
| Max. Recommended external chucking Diameter for standard soft top Jaw (mm) | 110 | 135 | 165 | 210 | 210 | 304 | 381 |
| Min. Recommended external chucking Diameter for standard soft top Jaw (mm) | 10 | 10 | 10 | 12 | 16 | 38 | 40 |
| Max. Speed (r.p.m.) | 8000 | 7000 | 6000 | 4900 | 4200 | 3300 | 2500 |
| Max. D.B. pull (kgf) | 948 | 1158 | 1450 | 2250 | 2850 | 3667 | 4793 |
| Clamping-force at Max. D.B. pull (Total jaw force) (kgf) | 1935 | 2399 | 3800 | 5600 | 7400 | 9600 | 12236 |
| GD² Moment of inertia w.D2 (kg•m²) | 0.006 | 0.0017 | 0.056 | 0.165 | 0.308 | 0.7 | 2.30 |
| Weight with standard soft top jaws (kg) | 3.8 | 6.5 | 11.5 | 21.3 | 33.5 | 52 | 115 |
| Matching cylinder / Max. pressure to operate chuck (kgf/cm²) RC | RC-4/23 | RC-5/16 | RC-6/19 | RC-8/17.5 | RC-10/18.5 | RC-12/18.5 | RC-15/15.3 |
Dimensions
| Dim/Symbol | TF2B-4 | TF2B-5 | TF2B-6 | TF2B-8 | TF2B-10 | TF2B-12 | TF2B-15 |
|---|---|---|---|---|---|---|---|
| A | 110 | 135 | 169 | 210 | 254 | 304 | 381 |
| B | 59 | 60 | 81 | 91 | 100 | 110 | 133 |
| C (H6) | 85 | 110 | 140 | 170 | 220 | 220 | 300 |
| F | 4 | 4 | 5 | 5 | 5 | 6 | 6 |
| H | 70.6 | 82.55 | 104.78 | 133.35 | 171.45 | 171.45 | 235 |
| J | 26 | 33 | 45 | 52 | 75 | 91 | 117.5 |
| K | M10 | 4-M10 | 6-M10 | 6-M12 | 6-M16 | 6-M16 | 6-M10 |
| L | 16 | 16 | 20 | 22 | 23 | 30 | 16 |
| M | 14 | 14 | 20 | 25 | 30 | 30 | 43 |
| N (Max) | 23 | 26.5 | 32 | 38.7 | 51 | 61.3 | 82 |
| N (Min) | 20.3 | 23.8 | 29.54 | 35 | 46.6 | 56 | 76.7 |
| O (Max) | 11.25 | 19.5 | 24 | 30 | 34.5 | 46.5 | 46.5 |
| O (Min) | 6.75 | 6 | 7.5 | 10.5 | 12 | 12 | 13.5 |
| P (Max) | 3.5 | 2 | 11 | 14.5 | 8.5 | 8 | 23 |
| P (Min) | -6.5 | -8 | -1 | -1.5 | -10.5 | -15 | 0 |
| Q | 23 | 23 | 32 | 37 | 42 | 52 | 62 |
| R | 10 | 10 | 12 | 14 | 16 | 21 | 24 |
| S | 17.5 | 20 | 19 | 23.5 | 25 | 28 | 43 |
| T | 24 | 26 | 29 | 39 | 43 | 51 | 66 |
| U (Max) | M32x1.5 | M40x1.5 | M55x2.0 | M60x2.0 | M85x2.0 | M100x2.0 | M130x2.0 |
| X | - | 12 | 16 | 16 | 16 | 20 | 20 |
| Y | - | 30 | 36 | 45 | 60 | 60 | 80 |
| A1 | - | 52 | 65 | 80 | 102 | 100 | 150 |
| M1 | - | M6 | M8 | M8 | M10 | M10 | M12 |
| t | - | 5 | 5 | 5 | 5 | 5 | 5 |
