- Compact and light weight, the CM-B Series hydraulic cylinder coolant collectors feature a bore size that is up to 20% larger than conventional cylinders. With precision finished piston bores and cool running rotary unions, years of trouble-free performance is assured.
Dimensions
| Model/Dim | CM08B | CM10B | CM12B | CM15B | CM18B | CM20B | CM25B |
|---|---|---|---|---|---|---|---|
| A | 78 | 78 | 118 | 118 | 158 | 158 | 198 |
| B | 61 | 75 | 87 | 96 | 123 | 140 | 180 |
| C | 42 | 42 | 42 | 44 | 44 | 44 | 44 |
| D | 84 | 84 | 88.5 | 88.5 | 88.5 | 88.5 | 105 |
| E | 115 | 115 | 131 | 151 | 151 | 151 | 215 |
| F | 60.5 | 60.5 | 76 | 96 | 96 | 96 | 126 |
| G | 90 | 90 | 107 | 147 | 147 | 147 | 200 |
| H | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
| Imin | 22 | 22 | 23 | 23 | 23 | 22.5 | 25 |
| Matching cylinder | RC-4 | RC-5 | RC-6 | RC-8 | RC-10 | RC-12 | RC-15 |
