4-jaw wedge type through-hole power chuck (with adaptor)

TF-4BA

Specification

Dimensions

Dim\Model	TF4B-6A5	TF4B-8A5	TF4B-8A6	TF4B-10A6	TF4B-10A8	TF4B-12A8	TF4B-15A8	TF4B-15A11
A	169	210	210	254	254	304	381	381
B	91	109	103	120	113	122	160	163
G	116	133.33	150	141.45	190	190	235	260
D	20	25	25	30	30	30	43	43
E	15	23	17	25	18	18	33	22
F	82.563	82.563	106.375	106.375	139.719	139.719	196.869	196.869
C (H6)	140	170	170	220	220	220	300	300
H	104.78	104.78	133.35	133.35	171.45	171.45	171.45	235
J	16	13	18	18	24	25	24	28
K	4xM10	4xM12	4xM12	4xM16	4xM16	4xM16	4xM20	4xM20
L	45	52	52	75	75	91	117.5	117.5
M	5	5	5	5	5	6	6	6
N (Max)	32	38.7	38.7	51	51	61.3	82	82
N (Min)	29.25	35	35	46.6	46.6	56	76.7	76.7
O (Max)	24	30	30	34.5	34.5	46.5	46.75	46.75
O (Min)	75	10.5	10.5	12	12	12	13.75	13.75
P (Max)	26	37.5	31.5	33.5	26.5	26	40	29
P (Min)	14	22.5	15.5	14.5	7.5	3	17	6
R	12	14	14	16	16	21	24	24
S	19	20.5	20.5	25	25	28	43	43
T	32	37	37	42	42	52	62	62
U (Max)	M55x2.0	M60x2.0	M60x2.0	M85x2.0	M85x2.0	M100x2.0	M130x2.0	M130x2.0
V	4xM6	4xM6	4xM6	6xM12	4xM8	4xM8	4xM10	4xM10
W	60	66	66	94	94	108	139	139
X	16	16	16	16	16	20	20	20
Y	36	45	45	60	60	60	80	80
A1	65	80	80	102	102	100	150	150
M1	M8	M8	M8	M10	M10	M10	M12	M12
t	5	5	5	5	5	5	5	5
Reference	Fig1	Fig2	Fig1	Fig2	Fig1	Fig1	Fig2	Fig1
