Key Features

INTERCITY  BUSES

Name of model: KESAVAN
Vehicle type : long-distance intercity bus-Intercity
Model number: IHN12FA-1
Chassis brand / model: HINO / RN8JSSA

Body size
Total length: 11,880 mm
Overall width: 2,495 mm
Overall height: 3,250 mm
Wheelbase: 6,000 mm
Front suspension length: 2,495 mm
Rear suspension length: 3,480 mm
Axle track: (front / rear) 2,040 / 1,820
Approach / departure angle: 7 ° / 7 °

Weight data
Maximum gross vehicle weight: 16,000 kg
Chassis weight: 5,190 kg

Main body configuration
Number of seats: 37

Door: sliding door at front and rear.
Windshield :,  laminated safety glass bonded in to the window frame.
Side windows:toughened glass and  laminated safety glass bonded in to the window frame.
Rear window:  laminated safety glass.
Mirrors: Manual adjustable
Air-conditioning system: SPAC_AC355 ceiling-mounted (Brand: sin shu che)

Chassis basic parameters
Frame: Step entrance type
Maximum power: 193 kW (263 PS) @ 2,500 RPM
Maximum speed: 113 km / h
Maximum climbing capacity: 31.9
Minimum turning radius: 9,100 mm
Maximum braking distance: x
Automatic transmission: : manual, five-speed+reverse gearbox
Reduction ratio: 4.3
Suspension system: air suspension, with a double-acting shock absorbers and levelling bar
Tires and Rims: 295/80R22.5 and 22.5x8.25-offset 165 mm
Brakes: Dual circuit, fully pneumatic brakes with brake automatic adjuster auxiliary brake, hydraulic retarder

Electrical system
Fuel tank capacity: 250L
Voltage: 24 V
Battery: 12V－540kC（150A∙h）x 2 pics
Generator: 24V－90A

Subordinate equipment:
GPS & GPRS system
Luggage rack
Luggage compartment
Cup holder
Wind outlet and passenger reading lights combination
Toilet
Front & the back door armrests
Fence
Seat
Fire extinguisher
Emergency hammer
Failure marked plate
Driving sunshade
Curtain
Reversing monitor
Turning and reversing buzzer
The INTERCITY Standard AV system device

Optional device:
The side of the car monitor
Rear route LED indicator
