RENEE-i

Key Features

Short-Distance Buses

Model name: RENEE-i
Vehicle type: short-distance intercity bus-Intercity
Model number: IHN12TB-1
Chassis brand / model: HINO / RK8JRSA

Body size
Total length: 11,653 mm
Overall width: 2,495 mm
Overall height: 3,250 mm
Wheelbase: 5,800 mm
Front suspension length: 2,452 mm
Rear suspension length: 3,401 mm
Axle track: (front / rear) 2,040 / 1,840
Approach / departure angle: 7 ° / 7 °

Weight data
Total weight: 14,500 kg
Chassis weight: 4,860 kg

Main body configuration
Number of seats: 37
Door: sliding door at front
Windshield :,  laminated safety glass bonded in to the window frame.
Side windows:toughened glass and  laminated safety glass bonded in to the window frame.
Rear window:  laminated safety glass.
Mirrors: Manual adjustable
Air-conditioning system: SPAC_AC262 Split
 (Brand: sin shu che)

Chassis basic parameters
Frame: 直通大樑式
Maximum power: 171.5kw (the 233PS) @ 2500RPM
Maximum speed: 95km / h
Maximum climbing capacity : 37.5
Minimum turning radius: 8,900 mm
Maximum braking distance: X
Transmission: manual, five-speed+reverse gearbox r
Reduction ratio: 5.125
Suspension system: Equal length of steel spring, attached double acting shock absorbers and stabilizer bar
Tires and rims :10.00-20-14PR / 20x7.00T-offset 162 mm
Brake system : double-loop, full pneumatic braking with brake automatic adjuster

Electrical system
Fuel tank capacity: 250L
Voltage: 24 V
Battery: 12V-540kC (150A. H) x 2 pics
Generator: 24V-90A

Subordinate equipment:
LED route indicator
GPS LED display
Luggage rack
Luggage compartment
Cup holder
Wind outlet and passenger reading lights combination
Front door armrests
Get off bell
Seat
Fire extinguisher
Emergency hammer
Failure marked plate
Driving sunshade
Parking sensor
Turning and reversing buzzer
The INTERCITY Standard AV system device

Optional device:
The side of the car monitor
Rear route LED indicator
GPRS System
