HIGH SPEED MILLING
HM65T
HIGH SPEED MILLING MACHINE HM65T

Application: graphite electrode, mold making, build-in high speed spindle, double column machining center.

Laser Calibration
Laser measurement of X and Y Axis using high quality super precision linear guide ways and ball screws.
Either 28mm or 40mm diameter used. (depending on model) assure precise positioning, accuracy and long endurance life.

Ball Bar Calibration
Renishaw ball bar testing used to test and record each machine's X and Y simultaneous movements.
This guarantees ideal and accurate table movement and ball screw backlash.

Simplified & Modulated Circuit Design
This makes easy maintenance due to modulated circuit board design, just change the pcb when trouble occurred.
Equipped with air cooling system for thermal regulation inside the generator.
This provides better efficiency and longer electronic life with in the system.

規格數據

Model Units HM65T
Spindle speed (max.) RPM 3000-30000
Spindle taper   HSK E40
Spindle motor (S1/S6) KW 10/13
Woking table size mm 540x650
T-slot mm 16x5x100
Max. load of table kg 300
Travel (XxYxZ) mm 500x600x300
Dist. from table surface to spindle nose mm 150-450
Work feed M/min 10
Rapid traverse (X,Y,Z) M/min 30,30,20
X.Y.Z. axis servo motor   AC servo motor
Total power consumption (max.) KAV 24
Net weight kg 4300

*Specifications are subject to change without prior notice.

Standard Accessories


● Work Lamp 1set
● Tool Kit 1set
● Coolant Equipment 1set
● Spindle Air Blast (for ATC) 1set
● Manual Pulse Generator (MPG) Hand Wheel 1SET
● Spindle Central Lubrication System (for ATC) 1set
● Cutting Air Blast 1set
● Working Alarm Indicator 1set
● Heat Exchanger for Electrical Cabinet
● Automatic Tool Length Measurement 1set

Optional Accessories


● Tool Shank
● Collect
● Pneumatic Freezing Dryer (ATC)
● 4th Axis Rotary Table
● AVR
● Ethernet Card
● X,Y,Z 3-axis Linear Scale
● Precision Optical Scale
● ATC
