Model

SLS1-80

SLS1-110

SLS1-160

Type

S

H

S

H

S

H

Tonnage Capacity

kN

800

1100

1600

Stroke Length

mm

150

100

180

110

200

130

Stroke per Minute

spm

40~75

55~110

35~65

50~100

30~55

40~85

Tonnage Rating Point

mm

5

5

6

Die Height

mm

330

300

350

320

400

360

Slide Adjustment

mm

80

90

100

Slide Area(LRxFB)

mm

700x460

800x520

900x580

Diameter of Shank Hole

mm

ø50.8

ø50.8

ø65

Bolster Area(LRxFB)

mm

900x680

900x460

1000x680

1000x520

1150x760

1150x600

Bolster Thickness

mm

140

155

165

Bolster Height(w/o Mounts)

mm

900

900

940

900

Main Motor(Fixed Speed+Inverter)

kW x P

7.5x4

11x4

15x4

Slide Adjustment Motor

kW x P

0.4x4

0.4x4

0.7x4

Window Opening(FBxUD)

mm

440x280

370x250

500x300

420x270

560x350

470x310

Foot Print

mm

1430x1470

1430x1420

1560x1600

1560x1550

1720x1780

1720x1730

Floor Space Required

mm

1630x1740

1765x1875

1905x2055

Press Height(w/o Mounts)

mm

2765

3000

3320

3280

Upper Die Weight

kg

300

350

500

Required Air Pressure

MPa

0.5

0.5

0.5

Model

SLS1-200

SLS1-250

SLS1-300

Type

S

H

S

H

S

H

Tonnage Capacity

kN

2000

2500

3000

Stroke Length

mm

220

150

250

180

280

180

Stroke per Minute

spm

25~45

35~70

22~40

30~60

20~35

25~50

Tonnage Rating Point

mm

6

6

6

Die Height

mm

450

400

450

400

500

400

Slide Adjustment

mm

110

120

120

Slide Area(LRxFB)

mm

1000x650

1100x720

1150x800

Diameter of Shank Hole

mm

ø65

ø65

ø65

Bolster Area(LRxFB)

mm

1250x840

1250x680

1350x900

1350x750

1400x1050

1400x850

Bolster Thickness

mm

180

180

200

Bolster Height(w/o Mounts)

mm

1020

1000

1020

1000

1040

1020

Main Motor(Fixed Speed+Inverter)

kW x P

18.5x4

22x4

30x4

Slide Adjustment Motor

kW x P

0.7x4

0.7x4

1.5x4

Window Opening(FBxUD)

mm

620x400

520x350

680x400

570x350

760x450

650x350

Foot Print

mm

1870x1980

1870x1930

1990x2150

1990x2100

2070x2297

2070x2247

Floor Space Required

mm

2055x2245

2175x2500

2255x2580

Press Height(w/o Mounts)

mm

3740

3720

4020

4000

4200

4030

Upper Die Weight

kg

800

1000

1250

Required Air Pressure

MPa

0.5

0.5

0.5

Model

SLS2-160

SLS2-200

SLS2-250

Type

S

H

S

H

S

H

Tonnage Capacity

kN

1600

2000

2500

Stroke Length

mm

200

130

230

150

250

180

Stroke per Minute

spm

30~55

40~85

25~45

35~70

22~40

30~55

Tonnage Rating Point

mm

6

5

7

5

7

6

Die Height

mm

450

400

500

450

550

450

Slide Adjustment

mm

100

100

120

Slide Area(LRxFB)

mm

1560×650

1850×750

1

2200×820

2

2500×820

Diameter of Shank Hole

mm

Φ51

Φ51

Φ51

Bolster Area(LRxFB)

mm

1850×760

2200×840

1

2500×920

2

2800×920

Bolster Thickness

mm

160

170

180

Bolster Height
(w/o Mounts)

mm

950

1000

1

1100

2

1150

Main Motor(Fixed Speed+Inverter)

kW×P

15x4

18.5x4

22x4

Slide Adjustment Motor

kW×P

1.5x4

1.5x4

1.5x4

Window Opening(FB)

mm

660

740

820

Window Opening(UD)

mm

400

320

450

350

460

350

Foot Print

mm

2600×1560

2930×1650

1

3290×1850

2

3690×1850

Floor Space Required

mm

2675×2405

3005×2495

1

3365×2695

2

3765×2695

Press Height

(w/o Mounts)

mm

3700

3640

4025

3965

1

4285

3

4150

2

4335

4

4370

Upper Die Weight

kg

1400

2000

1

2200

2

2500

Required Air Pressure

MPa

0.6

0.6

0.6

Model

SLS2-300

SLS2-400

SLS2-500

Type

S

H

S

H

S

H

Tonnage Capacity

kN

3000

4000

5000

Stroke Length

mm

280

150

300

200

300

200

Stroke per Minute

spm

20~35

25~45

15~30

25~40

15~30

25~40

Tonnage Rating Point

mm

7

7

7

7

7

7

Die Height

mm

550

450

600

450

600

450

Slide Adjustment

mm

120

120

120

Slide Area(LRxFB)

mm

1

2200×900

1

2200×1000

1

2200×1100

2

2500×900

2

2500×1000

2

2500×1100

3

2800×900

3

2800×1000

3

2800×1100

4

3100×900

4

3100×1000

4

3100×1100

Diameter of Shank Hole

mm

Φ51

Φ51

Φ51

Bolster Area(LRxFB)

mm

1

2500×1000

1

2500×1100

1

2500×1200

2

2800×1000

2

2800×1100

2

2800×1200

3

3100×1000

3

3100×1100

3

3100×1200

4

3400×1000

4

3400×1100

4

3400×1200

Bolster Thickness

mm

200

200

200

Bolster Height

(w/o Mounts)

mm

1、2

1150

1250

1250

 3、4

 1250

Main Motor(Fixed Speed+Inverter)

kW×P

30x4

37x4

45x4

Slide Adjustment Motor

kW×P

1.5x4

1.5x4

1.5x4

Window Opening(FB)

mm

900

1000

1100

Window Opening(UD)

mm

500

350

550

400

550

400

Foot Print

mm

1

3390×1930

1

3410×2070

1

3670×2170

2

3690×1930

2

3710×2070

2

3970×2170

3

4000X1930

3

4010X2070

3

4050×2170

4

4300×1930

4

4310×2070

4

4350×2170

Floor Space Required

mm

1

3490×2780

1

3485×3160

1

3745×3265

2

3765×2780

2

3785×3160

2

4075×3265

3

4075×2805

3

4085×3160

3

4375×3265

4

4375×2805

4

4385×3160

4

4675×3265

Press Height(w/o Mounts)

mm

1,2

4505

1,2

4355

1,2

4910

1,2

4770

1,2

5105

1,2

4955

3,4

4765

3,4

4665

3,4

4990

3,4

4840

3,4

5175

3,4

5025

Upper Die Weight

kg

1,2

2800

1,2

3000

1,2

3200

3,4

3000

3,4

3200

3,4

3400

Required Air Pressure

MPa

0.6

0.6

0.6
