Features:
The system adopts Windows CE controller
Six-axis programmable control, XYZ+ABC (can be replaced by XYZ+ABW or XYZ+ACW)
ATC system and A, B, C axis and spindle tilt option are available to increase machine functionally
Column movable master by linear slideway on X/Y/Z
Automatic lubrication
USB port
Use a 15-inch LCD touch screen, mouse, and standard keyboard
Presented in a dialog window with 3D stereo graphic description
Machining path and graphic display
Close-loop and feedback circuit design of 0.001mm resolution numerical linear scale is adopted on the 3 axis of the machine. Such design could get precise position setting, and increase the machining precision and efficiency of ORBIT-CUT
Dialogue programming editor that provides variety of hole enlargement modes (including function of edge search, center search, reference point search)
Automatic multi-step machining is available
Automatic home search function
ARC automatic arcing adjustment
Automatic center search and offset which could search the center and the deepest point of the hole
Movement of axis linear (3 axis), arc (2 axis), spiral (3 axis) and offset
Switch function: Language switch (Chinese/English) and unit system switch (Metric/Inch)
Single side sparking of 3 axis and 6 directions (plane rotation)
Automatic programming edition function: According to the material, area, initial current and wear rate do proper adjustment
