www.genndih.comProducts
Specification
| Operation mode | model | Dental mouth | Pressure bar | Type | Detailed specifications |
|---|---|---|---|---|---|
| Direct-acting | D262/263- | 1/8”-1/4” | AC 3-30 DC 1-30 |
2/2 Way Solenoid Valve NC |  |
| RD262/263- | 1/8”-1/4” | AC 10-30 DC 10-30 |
2/2 Way Solenoid Valve NO | |
|
| RD236- | 1/4” | AC 2-25 DC 2-25 |
2/2 Way Solenoid Valve NO | |
|
| B397- | 1/8” | AC 2-18 DC 2-18 |
3/2 Way Solenoid Valve NC | |
|
| D362/363- | 1/8”-1/4” | AC 1.5-18 DC 1.5-18 |
3/2 Way Solenoid Valve NC | |
|
| RD362/363- | AC 4-16 DC 4-13 |
3/2 Way Solenoid Valve NO | |||
| Guided linear motion | D884÷886- | 1/4”-1/2” | AC 16 DC 6 |
2/2 Way Solenoid Valve NC | |
| D187÷293- | 1/4”-1” | AC 16 | 2/2 Way Solenoid Valve NC | |
|
| CD187÷293- | DC 3.5-6 | ||||
| Guided | B203÷222- | 1/4”-1” | AC 16 DC 16 |
2/2 Way Solenoid Valve NC | |
| RB203÷222- | 2/2 Way Solenoid Valve NO | ||||
| D223÷225- | 1”1/4-2” | AC 16 DC 16 |
2/2 Way Solenoid Valve NC | |
|
| RD223÷225- | 2/2 Way Solenoid Valve NO | ||||
| D264÷266- | 1/4”-1/2” | AC 16 DC 7 |
2/2 Way Solenoid Valve NC | |
