Specification
| Model | D | R | A | B | H | 內六角 | X | Y | C |
|---|---|---|---|---|---|---|---|---|---|
| DPC4-M5 | 4 | M5 | 4 | 21 | 10 | 11.6 | 10.1 | 15.5 | |
| DPC4-01 | 4 | R1/8 | 7.5 | 21.5 | 10 | 3.0 | 11.6 | 10.1 | 15.5 |
| DPC4-02 | 4 | R1/4 | 9.5 | 19.7 | 14 | 3.0 | 11.6 | 10.1 | 15.5 |
| DPC6-M5 | 6 | M5 | 4 | 21.5 | 12 | 14 | 12.5 | 16 | |
| DPC6-01 | 6 | R1/8 | 7.5 | 21.5 | 12 | 4.0 | 14 | 12.5 | 16 |
| DPC6-02 | 6 | R1/4 | 9.5 | 20.5 | 14 | 4.0 | 14 | 12.5 | 16 |
| DPC6-03 | 6 | R3/8 | 10 | 20 | 17 | 4.0 | 14 | 12.5 | 16 |
| DPC6-04 | 6 | R1/2 | 13 | 23 | 21 | 4.0 | 14 | 12.5 | 16 |
| DPC8-01 | 8 | R1/8 | 7.5 | 24 | 14 | 5.0 | 16 | 14 | 18 |
| DPC8-02 | 8 | R1/4 | 9.5 | 24 | 14 | 6.0 | 16 | 14 | 18 |
| DPC-03 | 8 | R3/8 | 10 | 21.5 | 17 | 6.0 | 16 | 14 | 18 |
| DPC-04 | 8 | R1/2 | 13 | 23.5 | 21 | 6.0 | 16 | 14 | 18 |
| DPC10-01 | 10 | R1/8 | 7 | 28 | 17 | 5.0 | 19 | 16.5 | 20 |
| DPC10-02 | 10 | R1/4 | 9.5 | 30.5 | 17 | 6.0 | 20 | ||
| DPC10-03 | 10 | R3/8 | 10 | 27.5 | 17 | 8.0 | 20 | ||
| DPC10-04 | 10 | R1/2 | 13 | 25 | 21 | 8.0 | 20 | ||
| DPC12-01 | 12 | R1/8 | 7.5 | 29.5 | 19 | 5.0 | 21.5 | 18.5 | 21.5 |
| DPC12-02 | 12 | R1/4 | 9.5 | 31.5 | 19 | 6.0 | 21.5 | ||
| DPC12-03 | 12 | R3/8 | 10 | 28.5 | 19 | 8.0 | 21.5 | ||
| DPC12-04 | 12 | R1/2 | 13 | 28.5 | 21 | 8.0 | 21.5 | ||
| DPC16-03 | 16 | R3/8 | 10 | 35 | 24 | 8.0 | 27 | 24 | 24 |
| DPC16-04 | 16 | R1/2 | 13 | 33 | 24 | 10.0 | 27 | 24 | 24 |
