Remarks: For other specifications, please call to inquire.
Unit：mm
|
Model No. |
D Diameter |
R Corner Radius |
I Flute Length |
d Shank Diameter |
L Overall Length |
price |
|
2D ERVR 020024GR |
2 |
0.2R |
6 |
6 |
50 |
|
|
2D ERVR 020054GR |
2 | 0.5R | 6 | 6 | 50 | |
|
2D ERVR 025024GR |
2.5 | 0.2R | 7 | 6 |
50 |
|
| 2D ERVR 025054GR | 2.5 | 0.5R | 7 | 6 |
50 |
|
| 2D ERVR 030024GR | 3 | 0.2R | 8 | 6 |
50 |
|
|
2D ERVR 030054GR |
3 |
0.5R |
8 |
6 |
50 |
|
| 2D ERVR 030104GR | 3 | 1R | 8 | 6 |
50 |
|
| 2D ERVR 040024GR | 4 | 0.2R | 11 | 6 |
50 |
|
|
2D ERVR 040054GR |
4 |
0.5R |
11 |
6 |
50 |
|
|
2D ERVR 040104GR |
4 |
1R |
11 |
6 |
50 |
|
| 2D ERVR 050024GR | 5 | 0.2R | 13 | 6 |
50 |
|
|
2D ERVR 050054GR |
5 |
0.5R |
13 |
6 |
50 |
|
|
2D ERVR 050104GR |
5 |
1R |
13 |
6 |
50 |
|
| 2D ERVR 060024GR | 6 | 0.2R | 15 | 6 |
50 |
|
|
2D ERVR 060054GR |
6 |
0.5R |
15 |
6 |
50 |
|
|
2D ERVR 060104GR |
6 |
1R |
15 |
6 |
50 |
|
|
2D ERVR 080054GR |
8 |
0.5R |
20 |
8 |
60 |
|
|
2D ERVR 080104GR |
8 |
1R |
20 |
8 |
60 |
|
|
2D ERVR 100054GR |
10 |
0.5R |
30 |
10 |
75 |
|
|
2D ERVR 100104GR |
10 |
1R |
30 |
10 |
75 |
|
|
2D ERVR 100154GR |
10 |
1.5R |
30 |
10 |
75 |
|
| 2D ERVR 100204GR | 10 | 2R | 30 | 10 |
75 |
|
| 2D ERVR 100304GR | 10 | 3R | 30 | 10 |
75 |
|
|
2D ERVR 120054GR |
12 |
0.5R |
30 |
12 |
75 |
|
|
2D ERVR 120104GR |
12 |
1R |
30 |
12 |
75 |
|
|
2D ERVR 120204GR |
12 |
2R |
30 |
12 |
75 |
|
| 2D ERVR 160054GR | 16 | 0.5R | 50 | 16 |
100 |
|
|
2D ERVR 160104GR |
16 |
1R |
50 |
16 |
100 |
|
|
2D ERVR 160204GR |
16 |
2R |
50 |
16 |
100 |
|
|
2D ERVR 160304GR |
16 |
3R |
50 |
16 |
100 |
|
|
2D ERVR 200104GR |
20 |
1R |
50 |
20 |
100 |
|
|
2D ERVR 200204GR |
20 |
2R |
50 |
20 |
100 |
|
|
2D ERVR 200304GR |
20 |
3R |
50 |
20 |
100 |
|
